Suitable for indoor as well as outdoor parking area Parking lots, toll gate, goods yard, railway crossing, commercial premises, apartment block access shopping malls, hospitals, stadiums, business centers,etc.
| Working Temperature | -35℃~+85℃ |
| Power supply | AC 220V±10%, 110V±10%, 50/60HZ |
| Power consumption | 300W |
| Relative humidity | ≤90% |
| Remote control distance | ≥30m (open without interference) |
| Insulation grade | F |
| Parameter choose | direction, length, style of arm |
Operation Time Table (take straight arm as example)
| Boom type (m) | Open / close speed (s) | Time from open to close (s) |
| big type arm ≥6 | 2.5 | 4.5 |
| big type arm 4.5-6 | 1.8 | 3.8 |
| middle type arm 4-4.5 | 1.5 | 3.3 |
| middle type arm 3.5 | 1.2 | 2 |
| middle type arm 3 | 0.9 | 1.8 |
Note: 1. Open / close speed refers to the time it takes for the boom to rise from horizontal position to 70 degree angle;
2.Select the proper speed for the boom according to its type and length;
3. Please select the proper balance spring specification according to the boom type and boom length.
Optional Arm Type And Arm Color
Anti-collision round foaming arm( gold, red & white, folding arm is optional)
Square arm (red & white, blue & white, both sides can fix rubber, folding arm is optional)
Middle size octagonal arm (red & white, bronze blue, telescopic arm is optional)
Big size octagonal arm (red&white,bronze blue, red&sliver, orange&black, yellow &black, telescopic arm is optional)
E1 Two fencing arm(red&white,bronze blue,orange&black, yellow &black)
E2 Three fencing arm(red&white,bronze blue,orange&black, yellow &black)
90 degree / 180 degree arm ( red&white,bronze blue, orange&black, yellow &black)
Optional Accessories
