1. WIDEST OPENING
Compared to tripod turnstile and flap barrier, swing barrier allow widest opening clearance.
The slim form factor only take up minimum space from passage clearance space. 2 unit swing barrier can be installed on same lane to give maximum clearance 1210mm (inclusive 10 mm clearance).
2. CUSTOMIZE OPENING
Swing barrier allow customizable opening. Arylic gate can be cut short according to clearance available at site to
achieve perfect fitting.Control system will auto synchronize both swing barrier installed in the same lane. Both swing barrier will open and close at the same time.
3. EASY INTEGRATION
A push button or access control reader can be used to trigger the swing barrier to open via simple dry contact signal. After delay timer elapsed, swing barrier will automatically close back by itself.
4. DOUBLE SAFETY
Optional IR sensor can be installed to auto reverse the gate if obstacle is detected during closing. This prevent the closing gate to hit user that is still in the lane passage.
5. EMERGENCY RECOVERY
During power failure, swing barrier will automatically open for free pass through. This will fast escape in the event of emergency. When the power resume, swing barrier will automatically close back.
Working temperature | -20°C~+60°C |
Operating voltage | DC 24V |
Power supply input | AC220±10%V 50Hz/AC110±10% 60Hz |
Optimal flow rate | 25 to 30 person per minute |
Arm lenght | 600mm (default) |
Current | 3A |
Motor type | brushless DC motor |
Openning or closing time | 1s to 2s |
Reset time when power on | 3S |
